Section 8 I/O Ports
Rev. 7.00 Mar 10, 2005 page 223 of 652
REJ09B0042-0700
Port Data Register 7 (PDR7)
Bit
Initial value
Read/Write
7
P7
0
R/W
6
P7
0
R/W
5
P7
0
R/W
4
P7
0
R/W
3
P7
0
R/W
0
P7
0
R/W
2
P7
0
R/W
1
P7
0
R/W
76543210
PDR7 is an 8-bit register that stores data for port 7 pins P7
7
to P7
0
. If port 7 is read while PCR7
bits are set to 1, the values stored in PDR7 are read, regardless of the actual pin states. If port 7 is
read while PCR7 bits are cleared to 0, the pin states are read.
Upon reset, PDR7 is initialized to H'00.
Port Control Register 7 (PCR7)
Bit
Initial value
Read/Write
7
PCR7
0
W
6
PCR7
0
W
5
PCR7
0
W
4
PCR7
0
W
3
PCR7
0
W
0
PCR7
0
W
2
PCR7
0
W
1
PCR7
0
W
76543210
PCR7 is an 8-bit register for controlling whether each of the port 7 pins P7
7
to P7
0
functions as an
input pin or output pin. Setting a PCR7 bit to 1 makes the corresponding pin an output pin, while
clearing the bit to 0 makes the pin an input pin. PCR7 and PDR7 settings are valid when the
corresponding pins are designated for general-purpose input/output by bits SGS3 to SGS0 in
LPCR.
Upon reset, PCR7 is initialized to H'00.
PCR7 is a write-only register, which is always read as all 1s.
