Section 9 Timers
Rev. 7.00 Mar 10, 2005 page 263 of 652
REJ09B0042-0700
Pin Configuration
Table 9.7 shows the timer F pin configuration.
Table 9.7 Pin Configuration
Name Abbr. I/O Function
Timer F event input TMIF Input Event input pin for input to TCFL
Timer FH output TMOFH Output Timer FH toggle output pin
Timer FL output TMOFL Output Timer FL toggle output pin
Register Configuration
Table 9.8 shows the register configuration of timer F.
Table 9.8 Timer F Registers
Name Abbr. R/W Initial Value Address
Timer control register F TCRF W H'00 H'FFB6
Timer control/status register F TCSRF R/W H'00 H'FFB7
8-bit timer counter FH TCFH R/W H'00 H'FFB8
8-bit timer counter FL TCFL R/W H'00 H'FFB9
Output compare register FH OCRFH R/W H'FF H'FFBA
Output compare register FL OCRFL R/W H'FF H'FFBB
Clock stop register 1 CKSTPR1 R/W H'FF H'FFFA
