Renesas H8 Series Hardware Manual

Section 9 Timers
Rev. 7.00 Mar 10, 2005 page 289 of 652
REJ09B0042-0700
In this example, high-level input of less than five times the width of the sampling clock at the
input capture input pin is eliminated as noise.
Input capture
input signal
Sampling clock
Noise canceler
output
Eliminated as noise
Figure 9.10 Noise Canceler Timing (Example)
