Section 9 Timers
Rev. 7.00 Mar 10, 2005 page 297 of 652
REJ09B0042-0700
Table 9.14 Input Capture Input Signal Input Edges Due to Input Capture Input Pin
Switching, and Conditions for Their Occurrence
Input Capture Input
Signal Input Edge Conditions
Generation of rising edge When TMIG is modified from 0 to 1 while the TMIG pin is high
When NCS is modified from 0 to 1 while the TMIG pin is high, then
TMIG is modified from 0 to 1 before the signal is sampled five times by
the noise canceler
Generation of falling edge When TMIG is modified from 1 to 0 while the TMIG pin is high
When NCS is modified from 0 to 1 while the TMIG pin is low, then
TMIG is modified from 0 to 1 before the signal is sampled five times by
the noise canceler
When NCS is modified from 0 to 1 while the TMIG pin is high, then
TMIG is modified from 1 to 0 after the signal is sampled five times by
the noise canceler
Note: When the P1
3
pin is not set as an input capture input pin, the timer G input capture input
signal is low.
• Switching input capture input noise canceler function
When performing noise canceler function switching by modifying NCS in port mode register 2
(PMR2), which controls the input capture input noise canceler, TMIG should first be cleared to
0. Note that if NCS is modified without first clearing TMIG, an edge will be regarded as
having been input at the pin even though no valid edge has actually been input. Input capture
input signal input edges, and the conditions for their occurrence, are summarized in table 9.15.
Table 9.15 Input Capture Input Signal Input Edges Due to Noise Canceler Function
Switching, and Conditions for Their Occurrence
Input Capture Input
Signal Input Edge Conditions
Generation of rising edge When the TMIG pin is modified from 0 to 1 while TMIG is 1, then NCS
is modified from 0 to 1 before the signal is sampled five times by the
noise canceler
Generation of falling edge When the TMIG pin is modified from 1 to 0 while TMIG is 1, then NCS
is modified from 1 to 0 before the signal is sampled five times by the
noise canceler
