Section 10 Serial Communication Interface
Rev. 7.00 Mar 10, 2005 page 367 of 652
REJ09B0042-0700
Start receive
error processing
End of receive
error processing
[4]
Clear bits OER, PER,
FER to 0 in SSR
Yes
OER = 1?
Yes
Yes
FER = 1?
Break?
Yes
PER = 1?
No
No
No
No
Overrun error
processing
Framing error
processing
(A)
Parity error
processing
If a receive error has
occurred, read bits OER,
PER, and FER in SSR to
identify the error, and after
carrying out the necessary
error processing, ensure
that bits OER, PER, and
FER are all cleared to 0.
Reception cannot be
resumed if any of these
bits is set to 1. In the case
of a framing error, a break
can be detected by reading
the value of the RXD
32
pin.
[4]
Figure 10.8 Example of Data Reception Flowchart (Asynchronous Mode) (cont)
