Section 1 Overview
Rev. 7.00 Mar 10, 2005 page 2 of 652
REJ09B0042-0700
Table 1.1 Features
Item Specification
CPU High-speed H8/300L CPU
• General-register architecture
General registers: Sixteen 8-bit registers (can be used as eight 16-bit
registers)
• Operating speed
 Max. operating speed: 8 MHz (5 MHz for HD64F38024 and H8/38024S
Group)
 Add/subtract: 0.25 µs (operating at 8 MHz), 0.4 µs (operating at φ =
5 MHz)
 Multiply/divide: 1.75 µs (operating at 8 MHz), 2.8 µs (operating at φ =
5 MHz)
 Can run on 32.768 kHz or 38.4 kHz subclock (32.768 kHz only for
H8/38124 Group)
• Instruction set compatible with H8/300 CPU
 Instruction length of 2 bytes or 4 bytes
 Basic arithmetic operations between registers
 MOV instruction for data transfer between memory and registers
• Typical instructions
 Multiply (8 bits × 8 bits)
 Divide (16 bits ÷ 8 bits)
 Bit accumulator
 Register-indirect designation of bit position
Interrupts 22 interrupt sources
• 13 external interrupt sources (IRQ
4
, IRQ
3
, IRQ
1
, IRQ
0
, WKP
7
to WKP
0
,
IRQAEC)
• 9 internal interrupt sources
