Section 13 LCD Controller/Driver

Rev. 7.00 Mar 10, 2005 page 430 of 652

REJ09B0042-0700

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

SEG4 SEG4 SEG3 SEG3 SEG2 SEG2 SEG1 SEG1H'F740

H'F747

H'F74F

SEG29SEG30SEG30SEG31SEG31SEG32SEG32 SEG29

COM2 COM1 COM2 COM1 COM2 COM1 COM2 COM1

Display space

Space not used for display

Figure 13.5 LCD RAM Map (1/2 Duty)

Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0

SEG8 SEG7 SEG6 SEG5 SEG4 SEG3 SEG2 SEG1H'F740

H'F743

H'F74F

SEG25SEG26SEG27SEG28SEG29SEG30SEG31SEG32

COM1 COM1 COM1 COM1 COM1 COM1 COM1 COM1

Space not

used for

display

Display

space

Figure 13.6 LCD RAM Map (Static Mode)
