Renesas H8 Series

Section 1 Overview
Rev. 7.00 Mar 10, 2005 page 6 of 652
REJ09B0042-0700
Item Specification
Product Code
Mask ROM Version ZTAT Version F-ZTAT Version Package
ROM/RAM Size
(Byte)
Product lineup
HD64338024 HD64738024 HD64F38024R
HD64F38024
FP-80A
FP-80B
TFP-80C
TLP-85V (HD64F38024R only)
Die (mask ROM/F-ZTAT version
only)
32K/1K
HD64338023 — — FP-80A
FP-80B
TFP-80C
Die
24K/1K
HD64338022 — — FP-80A
FP-80B
TFP-80C
Die
16K/1K
HD64338021 — —
FP-80A
FP-80B
TFP-80C
Die
12K/512
HD64338020 — —
FP-80A
FP-80B
TFP-80C
Die
8K/512
HD64338024S — — FP-80A
TFP-80C
TLP-85V
Die
32K/1K
HD64338023S — — FP-80A
TFP-80C
TLP-85V
Die
24K/1K
HD64338022S — —
FP-80A
TFP-80C
TLP-85V
Die
16K/1K
HD64338021S — — FP-80A
TFP-80C
TLP-85V
Die
12K/512
HD64338020S — — FP-80A
TFP-80C
TLP-85V
Die
8K/512
HD64338124 — HD64F38124 FP-80A
TFP-80C
32K/1K
HD64338123 — — FP-80A
TFP-80C
24K/1K
HD64338122 — HD64F38122 FP-80A
TFP-80C
16K/1K
HD64338121 — —
FP-80A
TFP-80C
12K/512
HD64338120 — —
FP-80A
TFP-80C
8K/512
Refer to appendix E for information on product model numbers.
Note: * See section 4, Clock Pulse Generators, for the definition of φ and φ
w
.
