Section 16 Electrical Characteristics

Rev. 7.00 Mar 10, 2005 page 456 of 652

REJ09B0042-0700

Analog Power Supply Voltage and A/D Converter Operating Range

φ (MHz)

(0.5)

5.0

1.0

1.8 2.7 4.5 5.5

(V)

φ (kHz)

500

1000

625

1.8 2.7 4.5 5.5

(V)

• Active (medium-speed) mode

• Sleep (medium-speed) mode

• Active (high-speed) mode

• Sleep (high-speed) mode

Note: 3. When AV

= 1.8 V to 2.7 V, the operating range is limited to φ = 1.0 MHz when using an oscillator,

and is φ = 0.5 MHz to 1.0 MHz when using an external clock.
