Renesas H8 Series Hardware Manual

Section 16 Electrical Characteristics
Rev. 7.00 Mar 10, 2005 page 467 of 652
REJ09B0042-0700
Values
Item Symbol
Applicable
Pins Min Typ Max Unit Test Condition
Reference
Figure
Absolute
accuracy
——±3.0 LSB
AV
CC
= 2.7 V to 5.5 V
V
CC
= 2.7 V to 5.5 V
——±6.0
AV
CC
= 2.0 V to 5.5 V
V
CC
= 2.0 V to 5.5 V
— — ±8.0 Except the above
*
4
Conversion
time
12.4 — 124 µs AV
CC
= 2.7 V to 5.5 V
V
CC
= 2.7 V to 5.5 V
62 — 124 Except the above
Notes: 1. Set AV
CC
= V
CC
when the A/D converter is not used.
2. AI
STOP1
is the current in active and sleep modes while the A/D converter is idle.
3. AI
STOP2
is the current at reset and in standby, watch, subactive, and subsleep modes
while the A/D converter is idle.
4. Conversion time 62 µs
