Section 16 Electrical Characteristics
Rev. 7.00 Mar 10, 2005 page 478 of 652
REJ09B0042-0700
Values
Item Symbol Applicable Pins Min Typ Max Unit Test Condition Notes
Standby
mode
current
dissipation
I
STBY
V
CC
—0.3— µA
V
CC
= 3.0 V,
T
a
= 25°C
32 kHz crystal
oscillator not used
*
3
*
4
Reference
value
— 1.0 5.0 µA 32 kHz crystal
oscillator not used
*
3
*
4
RAM data
retaining
voltage
V
RAM
V
CC
2.0 — — V
I
OL
Output pins
except port 9
——0.5 mAAllowable
output low
current
(per pin)
P9
0
to P9
2
——25.0mA
*
1
——10.0
*
2
P9
3
to P9
5
——10.0mA
*
5
∑
I
OL
Output pins
except port 9
——20.0mAAllowable
output low
current
(total)
Port 9 — — 80.0 mA
Allowable
output high
current
(per pin)
–I
OH
All output pins — — 0.2 mA
Allowable
output high
current
(total)
∑
– I
OH
All output pins — — 10.0 mA
Notes: Connect the TEST pin to V
SS
.
1. Applied when the PIOFF bit in the port mode register 9 is 0.
2. Applied when the PIOFF bit in the port mode register 9 is 1.
