Renesas H8 Series

Section 16 Electrical Characteristics
Rev. 7.00 Mar 10, 2005 page 498 of 652
REJ09B0042-0700
Notes: Connect the TEST pin to V
SS
.
1. Pin states during current measurement.
Mode
RES
Pin Internal State
Other
Pins
LCD Power
Supply Oscillator Pins
Active (high-speed)
mode (I
OPE1
)
V
CC
Operates V
CC
Halted System clock oscillator:
crystal
Active (medium-
speed) mode (I
OPE2
)
Subclock oscillator:
Pin X
1
= GND
Sleep mode V
CC
Only on-chip timers
operate
V
CC
Halted
Subactive mode V
CC
Operates V
CC
Halted System clock oscillator:
Subsleep mode V
CC
Only on-chip timers
operate, CPU stops
V
CC
Halted
crystal
Subclock oscillator:
Watch mode V
CC
Only time base
operates, CPU stops
V
CC
Halted crystal
Standby mode V
CC
CPU and timers both
stop
V
CC
Halted System clock oscillator:
crystal
Subclock oscillator:
Pin X
1
= GND
2. Excludes current in pull-up MOS transistors and output buffers.
