Renesas H8 Series Hardware Manual

Appendix A CPU Instruction Set
Rev. 7.00 Mar 10, 2005 page 536 of 652
REJ09B0042-0700
Table A.1 lists the H8/300L CPU instruction set.
Table A.1 Instruction Set
Mnemonic Operation I H N Z V C
MOV.B #xx:8, Rd B #xx:8 → Rd8 2 
↔ ↔
↔ ↔
↔ ↔
↔ ↔
↔ ↔
↔ ↔
↔ ↔
↔ ↔
↔ ↔
↔ ↔
↔ ↔
↔ ↔
↔ ↔
↔ ↔
↔ ↔
↔ ↔
↔ ↔
↔ ↔
↔ ↔
↔ ↔
↔ ↔
↔ ↔
↔ ↔
↔ ↔
0  2
MOV.B Rs, Rd B Rs8 → Rd8 2  0  2
MOV.B @Rs, Rd B @Rs16 → Rd8 2  0  4
MOV.B @(d:16, Rs), Rd B @(d:16, Rs16)→ Rd8 4  0  6
MOV.B @Rs+, Rd B @Rs16 → Rd8 2  0  6
Rs16+1 → Rs16
MOV.B @aa:8, Rd B @aa:8 → Rd8 2  0  4
MOV.B @aa:16, Rd B @aa:16 → Rd8 4  0  6
MOV.B Rs, @Rd B Rs8 → @Rd16 2  0  4
MOV.B Rs, @(d:16, Rd) B Rs8 → @(d:16, Rd16) 4  0  6
MOV.B Rs, @−Rd B Rd16−1 → Rd16 2  0  6
Rs8 → @Rd16
MOV.B Rs, @aa:8 B Rs8 → @aa:8 2  0  4
MOV.B Rs, @aa:16 B Rs8 → @aa:16 4  0  6
MOV.W #xx:16, Rd W #xx:16 → Rd 4  0  4
MOV.W Rs, Rd W Rs16 → Rd16 2  0  2
MOV.W @Rs, Rd W @Rs16 → Rd16 2  0  4
MOV.W @(d:16, Rs), Rd W @(d:16, Rs16) → Rd16 4  0  6
MOV.W @Rs+, Rd W @Rs16 → Rd16 2  0  6
Rs16+2 → Rs16
MOV.W @aa:16, Rd W @aa:16 → Rd16 4  0  6
MOV.W Rs, @Rd W Rs16 → @Rd16 2  0  4
MOV.W Rs, @(d:16, Rd) W Rs16 → @(d:16, Rd16) 4  0  6
MOV.W Rs, @−Rd W Rd16−2 → Rd16 2  0  6
Rs16 → @Rd16
MOV.W Rs, @aa:16 W Rs16 → @aa:16 4  0  6
POP Rd W @SP → Rd16 2  0  6
SP+2 → SP
PUSH Rs W SP−2 → SP 2  0  6
Rs16 → @SP
#xx: 8/16 Rn @Rn @(d:16, Rn) @−Rn/@Rn+ @aa: 8/16 @(d:8, PC) @@aa Implied No. of States
Addressing Mode/
Instruction Length (bytes)
Condition Code
Operand Size
