Renesas H8 Series Hardware Manual

Appendix A CPU Instruction Set
Rev. 7.00 Mar 10, 2005 page 549 of 652
REJ09B0042-0700
Instruction Mnemonic
Instruction
Fetch
I
Branch
Addr. Read
J
Stack
Operation
K
Byte Data
Access
L
Word Data
Access
M
Internal
Operation
N
MOV MOV.W Rs, @Rd 1 1
MOV.W Rs, @(d:16, Rd) 2 1
MOV.W Rs, @–Rd 1 1 2
MOV.W Rs, @aa:16 2 1
MULXU MULXU.B Rs, Rd 1 12
NEG NEG.B Rd 1
NOP NOP 1
NOT NOT.B Rd 1
OR OR.B #xx:8, Rd 1
OR.B Rs, Rd 1
ORC ORC #xx:8, CCR 1
ROTL ROTL.B Rd 1
ROTR ROTR.B Rd 1
ROTXL ROTXL.B Rd 1
ROTXR ROTXR.B Rd 1
RTE RTE 2 2 2
RTS RTS 2 1 2
SHAL SHAL.B Rd 1
SHAR SHAR.B Rd 1
SHLL SHLL.B Rd 1
SHLR SHLR.B Rd 1
SLEEP SLEEP 1
STC STC CCR, Rd 1
SUB SUB.B Rs, Rd 1
SUB.W Rs, Rd 1
SUBS SUBS.W #1, Rd 1
SUBS.W #2, Rd 1
POP POP Rd 1 1 2
PUSH PUSH Rs 1 1 2
SUBX SUBX.B #xx:8, Rd 1
SUBX.B Rs, Rd 1
XOR XOR.B #xx:8, Rd 1
XOR.B Rs, Rd 1
XORC XORC #xx:8, CCR 1
