Appendix B Internal I/O Registers
Rev. 7.00 Mar 10, 2005 page 562 of 652
REJ09B0042-0700
WEGR—Wakeup Edge Select Register H'90 System Control
Bit
Initial value
Read/Write
7
WKEGS7
0
R/W
6
WKEGS6
0
R/W
5
WKEGS5
0
R/W
0
WKEGS0
0
R/W
2
WKEGS2
0
R/W
1
WKEGS1
0
R/W
4
WKEGS4
0
R/W
WKPn Edge Selected
0
WKPn pin falling edge detected
(n = 7 to 0)
1 WKPn pin rising edge detected
3
WKEGS3
0
R/W
