Renesas H8 Series

Appendix F Package Dimensions
Rev. 7.00 Mar 10, 2005 page 645 of 652
REJ09B0042-0700
Package Code
JEDEC
JEITA
Mass
(reference value)
TFP-80C

Conforms
0.4 g
*
Dimension including the plating thickness
Base material dimension
0.10
M
0.10
0.5 ± 0.1
0° − 8°
1.20 Max
14.0 ± 0.2
0.5
12
14.0 ± 0.2
60 41
120
80
61
21
40
*
0.17 ± 0.05
1.0
*
0.22 ± 0.05
0.10 ± 0.10
1.00
1.25
0.20 ± 0.04
0.15 ± 0.04
Unit: mm
Figure F.3 TFP-80C Package Dimensions
