Renesas H8 Series Hardware Manual

Section 2 CPU
Rev. 7.00 Mar 10, 2005 page 49 of 652
REJ09B0042-0700
[Legend]
op:
rm, rn:
abs:
IMM:
Operation field
Register field
Absolute address
Immediate data
15 087
op IMM rn
Operand:
Bit No.:
register direct (Rn)
immediate (#xx:3)
BIAND, BIOR, BIXOR, BILD, BIST
15 087
op 0
Operand:
Bit No.:
register indirect (@Rn)
immediate (#xx:3)
rn
0
0
0
0
0
0
0IMMop
15 087
op
Operand:
Bit No.:
absolute (@aa:8)
immediate (#xx:3)
abs
0000IMMop
Figure 2.7 Bit Manipulation Instruction Codes (cont)
