GX-6000 Operator’s Manual Configuring the Channels • 100
4 . Press and release POWER/ENTER. The available configuration options
are shown. The current setting for the channel will be flashing.
5 . Use â–²AIR and SHIFT â–¼ (PANIC) to move the cursor next to the desired
configuration for the selected channel. In the example below, the cursor
has been moved next to the H2S (H2S ) selection.
6 . Press and release POWER/ENTER to select the channel configuration.
NOTE: Each channel must have a gas assignment. If you change one
channel’s gas to something else, the two affected channels will end
up swapping places. In the example above, when you select H
2
S as
channel 1’s new gas, CH
4
, which used to be channel 1, would
automatically be assigned to channel 3, H
2
S’ old channel.
7 . Repeat Step 5 and Step 6 for any other channels you want to configure.
8 . Use SHIFT â–¼ (PANIC) to move the cursor next to the ESCAPE menu
item.
NOTE: If you want to exit to the main menu without saving any channel
configuration changes, press and release DISP/LOCK.
USER
CHANNEL 1
CH4 (HC )
O2 (OX )
H2S (H2S )
CO (CO )
VOC (SM1)
ESCAPE
USER
CHANNEL 1
CH4 (HC )
O2 (OX )
H2S (H2S )
CO (CO )
VOC (SM1)
ESCAPE
