113 • Replacing or Recharging the Batteries GX-6000 Operator’s Manual
2 . Confirm that the power adapter’s DC output cord is plugged into the
charger.
3 . If using an AC powered charging station, plug the AC adapter into an
electrical outlet.
Figure 19: Connecting the Charging Station’s AC Adapter
To AC
Outlet
Power Supply
Jack (on
bottom of
charger)
DC12V
AC Power
Supply
AC Powered Charging Station
