Event Messages List of Event Messages
Display Text Edit *) Cause Remedy
W4204-1:Setpoint * Too low Acquire setpoint.
W4204-2:Setpoint * Too big Acquire setpoint.
W4304:Fill value too low *
W4404:Excess feeding * Setpoint causes overfill.
W4404-1:Excess feeding * Setpoint exceeds maximum fill
value.
W4504:Out of Tolerance * Out of POSITIVE tolerance
W4504-1:Out of Tolerance * Refilling exceeds setpoint.
W4504-2:Out of Tolerance * SWA: below MINUS tolerance,
refilling cut off
W4504-10:Out of Tolerance * SWA: entered tolerance
excessive
W4604-1:Weight invalid * INVALID upon printout Repeat.
W4604-2:Weight invalid * OVERFLOW upon printout Reduce weight
and repeat.
W4605:Weight invalid * Upon printout INITIALISATION
or INVALID
Await
initialisation, or
check scale.
W4606:Weight invalid * ZEUS fixed tare weighing Repeat.
W4606-1:Weight invalid * ZEUS fixed tare weighing (Net
< 0)
Repeat.
A4804:Analog cable broken *
A5004-10:Function block linkage Wrong input linkage. Recreate linkage.
A5004-11:Function block linkage In fixed wiring
A5004-nnn:Function block linkage **) 1:Unknown function block
2:Wrong input number
3:Unknown output
A5104:Analog output wrong calibr.
M5204-1:Function not accessible * First weighing Dialog in menu
tree; exit.
M5204-2:Function not accessible * Second weighing Dialog in menu
tree; exit.
M5204-3:Function not accessible * Single weighing Dialog in menu
tree; exit.
M5304-1:Weighing aborted * ZEUS first weighing: Weight
cannot be used.
M5304-2:Weighing aborted * ZEUS second weighing: Weight
cannot be used.
M5304-3:Weighing aborted * ZEUS single weighing: Weight
cannot be used.
W5404:Empty check Bin tare out of configured limits Empty bin.
W5504:Contact check Filling spout misses bung hole Reposition bin.
W5604:Scale not permitted SWA: selected scale not
admitted for feeding
W5604-1:Scale not permitted FILLING/DISCHARGE scale:
seleted scale not admitted
W6020:PLS doesn't send External fieldbus master stops
polling controller
A6519-n:ICP Communication Error With ICP module to address n Check external
I/O module.
W7002-1:EDP Error * Internal status processing No remedy.
W7003-1:EDP Error * Internal timer Repeat later.
W7003-2:EDP Error * Establishing connection to
interface task
Repeat later.
W7003-3:EDP Error * Message sending error Repeat later.
W7003-5:EDP Error * Order timeout elapsed Repeat later.
BV-H2313 GB 0630 DISOMAT
®
Opus – Operating Manual
- 138 - © Schenck Process GmbH, Darmstadt
