Technical data • 129
English
17-10-05-353-002g_10-2020 B
12.6 Analysis parameters
NOTE
These instructions for use describe the maximal available functional
scope of the device. The actual functional scope of your device may
be less than this.
Analysis parameter Display Analysis module
Bioimpedance vector analysis
(BIVA)
• Normal range display of R and X
c
in coordinate
system in relation to height
• 50 %, 75 %, 95 % percentiles in the form of
tolerance ellipses
Fluid
Health risk
Body mass index (BMI)
Absolute in kg/m
2
Development/growth
Extracellular water (ECW) Absolute in l Fluid
Fat-free mass (FFM) Absolute in kg Function/rehabilitation
Fat mass (FM)
• Absolute in kg
• Relative to weight in %
Energy
Function/rehabilitation
Total energy expenditure (TEE) Absolute in MJ/d or kcal/d Energy
Total body water (TBW) Absolute in l Fluid
Weight (W) Absolute in kg Development/growth
Height (H) Absolute in m Development/growth
Extracellular water (ECW)/total
body water (TBW)
Relative in % Fluid (international)
Energy stored in the body (E
body
)
Absolute in MJ or kcal Energy
Body composition chart (BCC):
Mass indices
Fat-free mass index (FFMI)
Fat mass index (FMI)
• Absolute in kg/m
2
• Normal range display
• 50 %, 75 %, 95 % percentiles in the form of
tolerance ellipses
Function/rehabilitation
Health risk
Phase angle (φ)
• Absolute in degrees
• Normal range display
Health risk
Reactance (X
c
)
Absolute in ohms
Fluid
Health risk
Resistance (R) Absolute in ohms
Fluid
Health risk
Resting energy expenditure
(REE)
Absolute in MJ/d or kcal/d Energy
Skeletal muscle mass (SMM)
• Absolute in kg
• Normal range display
Function/rehabilitation
Visceral adipose tissue (VAT) Absolute in l Health risk
Blood pressure, non-invasive
(NIBP)
Absolute in mmHg Vital signs
Body temperature (TEMP) Absolute in °C Vital signs
Pulse rate (PR)
Absolute in min
-1
(based on NIBP or SpO
2
)
Vital signs
Oxygen saturation (SpO
2
)
Relative in % Vital signs
