Function diagrams
Input/Output Terminals
2-512
© Siemens AG 2011 All Rights Reserved
SINAMICS G120 Control Units CU230P-2 Parameter Manual (LH9), 01/2011
2.4 Input/Output Terminals
Function diagrams
2220 – Digital inputs, electrically isolated (DI0 ... DI5) 2-513
2222 – Analog inputs as Digital inputs (DI11 ... DI12) 2-514
2230 – Digital outputs (DO0 ... DO2) 2-515
9566 – Analog inputs 0 ... 1 (AI0 ... AI1) 2-516
9568 – Analog input 2 (AI2) 2-517
9576 – Temperature evaluation Ni1000/PT1000 (AI3) 2-518
9572 – Analog outputs 0 ... 1 (AO0 ... AO1) 2-519
