Diagnostics
5.3 Fault and alarm messages
Function Manual
112 Function Manual, 01/2011, 6SL3097-4AB10-0BP3
Note
An external fault or alarm is triggered by a 1/0 signal.
An external fault and alarm do not usually mean that an internal drive message has been
generated. The cause of an external fault and warning should, therefore, be remedied
outside the drive.
5.3.4 Parameters and function diagrams for faults and alarms
Function diagrams (see SINAMICS S110 List Manual)
● 1710 Overview diagram – monitoring functions, faults, alarms
● 8060 Diagnostics - Fault buffer
● 8065 Diagnostics - Alarm buffer
● 8070 Diagnostics - Fault/alarm trigger word r2129
● 8075 Diagnostics - Fault/alarm configuration
Overview of important parameters (see SINAMICS S110 List Manual)
● r0944 Counter for fault buffer changes
...
● p0952 Fault counter
● p2100[0...19] Fault code for fault reaction selection
...
● r2139 Status word for faults
● r3120[0...63] Component number fault
● r3121[0...63] Component number alarm
● r3122[0...63] Diagnostics attribute fault
● r3123[0...63] Diagnostics attribute alarm
