Communication
9.2 Communication according to PROFIdrive
Function Manual
558 Function Manual, 01/2011, 6SL3097-4AB10-0BP3
9.2.3.4 Control and status words for encoder
Description
The process data for the encoders is available in various telegrams. For example, telegram 3
is provided for speed control with 1 position encoder and transmits the process data of
encoder 1.
The following process data is available for the encoders:
● Gn_STW encoder n control word (n = 1, 2)
● Gn_ZSW encoder n status word
● Gn_XIST1 encoder n act. pos. value 1
● Gn_XIST2 encoder n act. pos. value 2
Note
Encoder 1: Motor encoder
Encoder 2: Direct measuring system
Example of encoder interface
6ODYH0DVWHU
352),%86
*B67:
*B67:
*B =6:
*B=6:
*B;,67 *B;,67
*B;,67
*B67:
*B67:
*B =6:
*B=6:
*B;,67 *B;,67
*B;,67
Figure 9-8 Example of encoder interface (encoder-1: two actual values, encoder -2: one actual
value)
