Siemens SINAMICS S110 Function Manual

Diagnostics
5.1 Diagnostics via LEDs
Function Manual
Function Manual, 01/2011, 6SL3097-4AB10-0BP3
89
5.1.2 LEDs after the Control Unit CU305 has booted
Table 5- 2 Control Unit CU305 – description of the LEDs after booting
LED Color Status Description, cause Remedy
- off Electronics power supply is missing or outside
permissible tolerance range.
-
Continuous The component is ready and cyclic DRIVE-CLiQ
communication takes place or the Control Unit waits
for initial commissioning.
-
Flashing
2 Hz
Writing to the memory card
1)
-
Green
Flashing
0.5 Hz
Commissioning/Reset or
Safety commissioning/Reset
-
Red Flashing
2 Hz
At least one fault is present in this component. Remedy and
acknowledge fault
Green/
Red
Flashing
0.5 Hz
Control Unit CU305 is ready for operation.
However there are no software licenses.
Obtain licenses.
RDY
(READY)
Green/
orange or
red/
orange
Flashing
1 Hz
Component detection via LED is activated
(p0124[0]).
Note:
Both options depend on the LED status when
component recognition is activated via p0124[0] = 1.
-
- off Cyclic communication has not (yet) taken place.
Note:
The PROFIdrive is ready to communicate when the
Control Unit is ready to operate (see LED RDY).
-
Continuous Cyclic communication is taking place. - Green
Flashing
0.5 Hz
Cyclic communication is not yet running fully.
Possible reasons:
 The controller is not transferring any setpoints.
 During isochronous operation, no global control
(GC) or a faulty global control (GC) is transferred
by the controller.
-
Red Continuous Cyclic communication has been interrupted. Remedy fault
COM
PROFIdrive
cyclic operation/
CU305 DP
Orange Flashing
2 Hz
Firmware CRC error. Make sure that the
memory card has
been inserted
properly.
1)
Replace the memory
card.
1)
Replace Control Unit.
Carry-out a POWER
ON.
- off Cyclic communication has not (yet) taken place.
Note:
The CAN is ready to communicate when the Control
Unit is ready to operate (see LED RDY).
- COM/
CU305 CAN
Green Continuous Cyclic communication is taking place. -
