Siemens SINAMICS S110 Function Manual

Basic information about the drive system
10.6 Replacing SMI and DQI components
Function Manual
Function Manual, 01/2011, 6SL3097-4AB10-0BP3
683
10.5.3 Analog Input
Properties
● Hardware input filter set permanently
● Simulation mode parameterizable
● Adjustable offset
● Signal can be inverted via binector input
● Adjustable absolute-value generation
● Noise suppression (p0768)
● Enabling of inputs via binector input
● Output signal available via connector output
● Scaling
● Smoothing
NOTICE
Scaling parameters p0757 to p0760 do not limit the voltage/current values.
Function diagram (see SINAMICS S110 List Manual)
● 2040 Analog input (AI)
10.6 Replacing SMI and DQI components
Replacement of SINAMICS Sensor Module Integrated or DRIVE-CLiQ Sensor Integrated
If a defect occurs in a SINAMICS Sensor Module Integrated (SMI) or a DRIVE-CLiQ Sensor
Integrated (DQI), contact your local Siemens office for a repair.
