Page #684 background image
Basic information about the drive system
10.5 Inputs/outputs
Function Manual
682 Function Manual, 01/2011, 6SL3097-4AB10-0BP3
Digital output
Properties
Separate power supply for the digital outputs.
Source of output signal can be selected by parameter.
Signal can be inverted by parameter.
Status of output signal can be displayed
as a binector output
as a connector output
Note
Before the digital output can function, its own electronics power supply must be
connected.
Function diagrams (see SINAMICS S110 List Manual)
2032 digital output (DO 16)
Bidirectional digital inputs/outputs
Properties
Can be parameterized as digital input or output.
When set as digital input:
Four "high-speed inputs" on Control Unit
If these inputs are used, for example, for the "flying measurement" function, they act
as "high-speed inputs" with virtually no time delay when the actual value is saved.
The properties of the "pure" digital outputs apply.
When set as digital output:
The properties of the "pure" digital output apply.
Sharing of bidirectional input/output resources by the CU and higher-level control (see
section "Use of bidirectional inputs/outputs on the CU")
Function diagrams (see SINAMICS S110 List Manual)
2030 Bidirectional digital inputs/outputs (DI/DO 8 ... DI/DO 9)
2031 Bidirectional digital inputs/outputs (DI/DO 10 ... DI/DO 11)
