Connector designation: X111, X112, X113, X114
Connector type: 40-pin plug connector
Special feature: No galvanic isolation, with interlock
Max. cable length: 2 m
Table 7-50 Assignment of connector X111
Pin Signal name Type Pin Signal name Type
1 Ground V 2 Ground V
3 DI112.0 I 4 DO112.0 O
5 DI112.1 6 DO112.1
7 DI112.2 8 DO112.2
9 DI112.3 10 DO112.3
11 DI112.4 12 DO112.4
13 DI112.5 14 DO112.5
15 DI112.6 16 DO112.6
17 DI112.7 18 DO112.7
19 DI113.0 20 DO113.0
21 DI113.1 22 DO113.1
23 DI113.2 24 DO113.2
25 DI113.3 26 DO113.3
27 DI113.4 28 DO113.4
29 DI113.5 30 DO113.5
31 DI113.6 32 DO113.6
33 DI113.7 34 DO113.7
35 DI120.0 36 DI120.1 I
37 DI120.2 38 DI120.3 I
39 Reserved 40 Reserved
Anschließbare Komponenten
7.5 MCP Interface PN
PPU and components
Manual, 05/2015, 6FC5397-2DP40-3BA4 165
