Siemens SINUMERIK 828D

Table 7-51 Assignment of connector X112
Pin Signal name Type Pin Signal name Type
1 Ground V 2 Ground V
3 DI114.0 I 4 DO114.0 O
5 DI114.1 6 DO114.1
7 DI114.2 8 DO114.2
9 DI114.3 10 DO114.3
11 DI114.4 12 DO114.4
13 DI114.5 14 DO114.5
15 DI114.6 16 DO114.6
17 DI114.7 18 DO114.7
19 DI115.0 20 DO115.0
21 DI115.1 22 DO115.1
23 DI115.2 24 DO115.2
25 DI115.3 26 DO115.3
27 DI115.4 28 DO115.4
29 DI115.5 30 DO115.5
31 DI115.6 32 DO115.6
33 DI115.7 34 DO115.7
35 DI120.4 36 DI120.5 I
37 DI120.6 38 DI120.7 I
39 Reserved 40 Reserved
Anschließbare Komponenten
7.5 MCP Interface PN
PPU and components
166 Manual, 05/2015, 6FC5397-2DP40-3BA4
