Siemens SINUMERIK 828D

Table 7-52 Assignment of connector X113
Pin Signal name Type Pin Signal name Type
1 Ground V 2 Ground V
3 DI116.0 I 4 DO116.0 O
5 DI116.1 6 DO116.1
7 DI116.2 8 DO116.2
9 DI116.3 10 DO116.3
11 DI116.4 12 DO116.4
13 DI116.5 14 DO116.5
15 DI116.6 16 DO116.6
17 DI116.7 18 DO116.7
19 DI117.0 20 DO117.0
21 DI117.1 22 DO117.1
23 DI117.2 24 DO117.2
25 DI117.3 26 DO117.3
27 DI117.4 28 DO117.4
29 DI117.5 30 DO117.5
31 DI117.6 32 DO117.6
33 DI117.7 34 DO117.7
35 DI121.0 36 DI121.1 I
37 DI121.2 38 DI121.3 I
39 Reserved 40 Reserved
Anschließbare Komponenten
7.5 MCP Interface PN
PPU and components
Manual, 05/2015, 6FC5397-2DP40-3BA4 167
