1.4 Document history
The overview below summarizes the most important changes in the documentation when
compared to the previous edition.
Edition Comment
08/2020 First edition
1.5 Product compatibility TH320/420
The following table describes the compatibility between the edition of this manual, the device
version, the engineering system and the associated EDD.
Manual
edition
Comments Device version Compatible version of device integration package
08/2020 New device fea‐
tures
HART 7
TH320/420: 01.02.xx or higher
SIMATIC PDM V9.1 EDD: 01.00.00 or higher
AMS Device Manager V13.3 EDD: 01.00.01 or higher
DTM EDD: 01.00.01 or higher
Field Communicator FC
375/475
EDD: 01.00.01 or higher
1.6 Checking the consignment
1. Check the packaging and the delivered items for visible damages.
2. Report any claims for damages immediately to the shipping company.
3. Retain damaged parts for clari󹪝cation.
4. Check the scope of delivery by comparing your order to the shipping documents for
correctness and completeness.
WARNING
Using a damaged or incomplete device
Risk of explosion in hazardous areas.
• Do not use damaged or incomplete devices.
Note
Bending of the sensor during transport
Sensors that are delivered without conduit can be bent during transport. This bending does not
a󹪜ect the quality of the sensor. The mineral insulated cables used for SITRANS TS are bendable.
• Bend the sensor into the required position before you install it. When bending the sensor,
note the bending radius of ≥ 24 mm and the length NBL of 60 mm at the tip that is not
bendable.
Introduction
1.6 Checking the consignment
SITRANS TS100/TS200/TS300/TS500/TSinsert/TSthermowell
10 Operating Instructions, 08/2020, A5E47810090-AA
