Page #146 background imageLoading...
Page #146 background image
11.7 Display
Ambient conditions
Ambient temperature -20 ... +85 °C (-7 ... +185 °F)
You can 󹪝nd the data for use in hazardous areas in
the respective certi󹪝cate.
Storage temperature -40 ... +85 °C (-40 ... +185 °F)
You can 󹪝nd the data for use in hazardous areas in
the respective certi󹪝cate.
Best readability -10 ... +70 °C (14 ... +158 °F)
Power supply
Power supply Is provided by the temperature transmitter
Own power consumption < 3 mA
Voltage drop over terminals < 2.5 V
Display
Area of application SITRANS TF and SITRANS TS500 temperature trans‐
mitter
Measuring frequency ≥ 2 Hz
Local display Maximum 5 decimal places
Display range -99999 ... +99999
Decimal point change Automatically
Error warning According to NAMUR NE 107
Mechanical construction
Dimensions Diameter: 64.3 mm (2.53")
Height: 15 ... 22.5 mm (0.6 ... 0.88")
Installation Plug in
Enclosure material Plastic
Wiring Plug-in connection
Ambient conditions
Pollution degree according to IEC 61010 1 ... 2
Ambient temperature range 0 ... 50 °C (+32 ... +122 °F)
Storage temperature range -20 ... +65 °C (-4 ... +149 °F)
Relative humidity 5 ... 80% at 25 °C (no condensation)
USB port
Connection USB 1.1, compatible with USB 2.0
USB current Standard, < 200 mA
Technical data
11.7 Display
SITRANS TS100/TS200/TS300/TS500/TSinsert/TSthermowell
146 Operating Instructions, 08/2020, A5E47810090-AA
