Parame‐
ter ID
Parameter name on
the display
Meaning
13 LOOP TEST Loop test
14 TRIM INPUT 1 One-point calibration input 1
15 TRIM INPUT 2 One-point calibration input 2
16 CHANGE PIN Change User PIN
17 PIN RECOVERY PIN recovery
18 USER PIN Enable and disable User PIN
19 MIN INPUT 1 Minimum measured peak value at Input 1
20 MAX INPUT 1 Maximum measured peak value at input 1
21 MIN INPUT 2 Minimum measured peak value at input 2
22 MAX INPUT 2 Maximum measured peak value at Input 2
23 MIN ETEMP Minimum transmitter electronics temperature
24 MAX ETEMP Maximum transmitter electronics temperature
25 BUTTON LOCK Enable and disable button lock
The parameter ID is written after the parameter name in parentheses from here on out. Example:
Parameter "Damping value" [11].
Navigating in the parameter view
Requirement
The button lock is disabled.
Disabling button lock (Page 94)
Procedure
1. Use the or buttons to navigate within the parameters.
To navigate faster, keep the or button pressed.
After the last parameter, you jump to the rst parameter, and vice versa.
2. To switch to edit view, press the button.
3. To return to the measurement view, press the button.
7.1.2.4 Edit view
You change the parameter values in the edit view. Wizards are available for specic parameters.
Parameter values
There are various parameter values:
• Enumerations (e.g. unit type)
• Numerical values (e.g. damping)
Operating
7.1 Local operation
SITRANS TS100/TS200/TS300/TS500/TSinsert/TSthermowell
Operating Instructions, 08/2020, A5E47810090-AA 63
