Figure 12-5 Dimensional drawings SITRANS TS500, types 2 and 2N - dimensions in mm (inch)
12.5.2 SITRANS TS500, types 2G and 2F
/(
G
'
+1
;
% 1+

'
8
.
(
/(
G
'
+1
;
% 1+

'
8
① Type 2G, pipe version with screw-in nipple and extension
② Type 2F, pipe version with 󹪞ange and extension
B Length of measuring insert H
1
Type Axx: 41 (1.61)
Type Bxx: 26 (1.02)
∅d External diameter of measuring insert (6 (0.24)) K Penetration depth
∅D External diameter of process connection LE Cable inlet
∅D3 Internal diameter of protective tube N Nominal length
E Thread dimension of process connection U Mounting length
H Height of head X Extension
Figure 12-6 Dimensional drawings SITRANS TS500, types 2G and 2F - dimensions in mm (inch)
Dimension drawings
12.5 SITRANS TS500
SITRANS TS100/TS200/TS300/TS500/TSinsert/TSthermowell
160 Operating Instructions, 08/2020, A5E47810090-AA
