Siemens SITRANS TSinsert - Connection Type for Input 2 [05]

RTD Ni50 – GOST 6651-2009 (α =
0.00617)
N50 G RTD Ni50 – GOST 6651-2009 (α = 0.00617)
RTD Ni100 – GOST 6651-2009 (α
= 0.00617)
N100G RTD Ni100 – GOST 6651-2009 (α = 0.00617)
Micro-Volts bipolar µV± Micro-Volts bipolar
Milli-Volts bipolar mV± Milli-Volts bipolar
Volts bipolar V± Volts bipolar
TC Type B - IEC 584 TC B Thermocouple Type B - IEC 584
TC Type W5 - ASTM E 988 TC W5 Thermocouple Type W5 - ASTM E 988
TC Type W3 - ASTM E 988 TC W3 Thermocouple Type W3 - ASTM E 988
TC Type E - IEC 584 TC E Thermocouple Type E - IEC 584
TC Type J - IEC 584 TC J Thermocouple Type J - IEC 584
TC Type K - IEC 584 TC K Thermocouple Type K - IEC 584
TC Type N - IEC 584 TC N Thermocouple Type N - IEC 584
TC Type R - IEC 584 TC R Thermocouple Type R - IEC 584
TC Type S - IEC 584 TC S Thermocouple Type S - IEC 584
TC Type T - IEC 584 TC T Thermocouple Type T - IEC 584
TC Type L - DIN 43710 TC L Thermocouple Type L - DIN 43710
TC Type U - DIN 43710 TC U Thermocouple Type U - DIN 43710
TC Type Lr - GOST 3044-84 TC LR Thermocouple Type Lr - GOST 3044-84
RTD Cux – GOST 6651-2009 (α =
0.00428)
CUX G RTD Cux – GOST 6651-2009 (α = 0.00428)
1)
RTD Ptx – GOST 6691-2009 (α =
0.00391)
PTX G RTD Ptx – GOST 6691-2009 (α = 0.00391)
1)
Custom Linearization (CUSTOM
SPECIFIC)
CUSTM Custom Linearization (CUSTOM SPECIFIC)
Micro-Volts unipolar (CUSTOM
SPECIFIC)
µV Micro-Volts unipolar (CUSTOM SPECIFIC)
Milli-Volts unipolar (CUSTOM
SPECIFIC)
mV Milli-Volts unipolar (CUSTOM SPECIFIC)
Volts unipolar (CUSTOM SPECIF‐
IC)
V Volts unipolar (CUSTOM SPECIFIC)
None NONE No input type selected
Factory set‐
ting:
None NONE No input type selected
1)
Value x matches customer RTD value
8.3.5 Connection type for input 2 [05]
Selects the connection type for input 2 depending on the selected sensor.
Indication on the dis‐
play
WIRING 2
Setting range: 2, 3, 4-wire
Factory setting: -
Parameter assignment
8.3 Parameter assignment over device with display
