12.4 SITRANS TS300
SITRANS TS300 Modular:



'
'
G
8
1
;+
% 1




B Length of measuring insert H Height of head
∅d External diameter of measuring insert N Nominal length
∅D External diameter of process connection U Mounting length (see process connection
options)
∅D3 Internal diameter of protective tube X Extension (see process connection options)
Figure 12-3 Dimensions in mm (inch)
Dimension drawings
12.4 SITRANS TS300
SITRANS TS100/TS200/TS300/TS500/TSinsert/TSthermowell
Operating Instructions, 08/2020, A5E47810090-AA 155
