Technical data
11
11.1 Rated conditions
Storage
Storage temperature -40 ... +80 °C (-40 ... +176 °F)
Degree of protection in accordance with EN 60529 See nameplate.
The degree of protection is achieved when the device is moun‐
ted correctly. See section Installing/mounting (Page 27).
11.1.1 Minimum permissible ambient temperatures in the connection area of the
sensor
Sensor Maximum permitted ambient temperatures in the connection area of the
sensor
SITRANS TSinsert/TS100/TS200 -40 °C
SITRANS TS300 -20 °C
SITRANS TS500
• SITRANS TS500
• SITRANS TS500 with SITRANS
TH320/TH420 and display
• SITRANS TH100/TH200/TH300/
TH400 with HAN 7D plug-in connec‐
tor and M12 (option codes G12 and
G13)
-40 °C
SITRANS TS500 type 7MC75.. with head‐
er type AG0 and AU0 (option G and U) in
non-SIL applications, without display,
optional with installed SITRANS TH320/
TH420
-50 °C
• Electronics and cable glands of the
SITRANS TS500
• Electronics and cable glands are designed for the minimum permissible am‐
bient temperature of the SITRANS TS500.
• When the electronics or the cable gland are not designed for the minimum
permissible ambient temperature, the minimum permissible ambient tem‐
perature of the entire SITRANS TS500 is reduced accordingly.
• See the datasheets of the electronics and the cable glands.
See also
Nameplate structure (Page 20)
SITRANS TS100/TS200/TS300/TS500/TSinsert/TSthermowell
Operating Instructions, 08/2020, A5E47810090-AA 127
