Siemens SITRANS TSinsert - SITRANS TS500, Types 4 and 4 F

12.5.5 SITRANS TS500, types 4 and 4F
LE
M18x1,5
B = N + H
1
- 1
B = N + H
1
- 1
Ød
ØD4
C
XL
HN
ØD3
ØD
ØD2
1
ØD4
LE
M18x1,5
Ød
HN
XL
ØD2
U
C
ØD
ØD3
1


① Type 4, full material version, with extension
② Type 4F, full material version, with 󹪞ange and extension
B Length of measuring insert E Thread dimension of process con‐
nection
C Cone length = U
min
H Height of head
∅d External diameter of measuring insert (6 (0.24)) H
1
Type Axx: 41 (1.61)
Type Bxx: 26 (1.02)
∅D External diameter of process connection K Penetration depth
∅D1 Internal diameter of tip L Length of protective sleeve
∅D2 External diameter of tip LE Cable inlet
∅D3 Internal diameter of protective tube N Nominal length
∅D4 External diameter of extension U Mounting length
X Extension
Dimension drawings
12.5 SITRANS TS500
SITRANS TS100/TS200/TS300/TS500/TSinsert/TSthermowell
Operating Instructions, 08/2020, A5E47810090-AA 163
