12.5.25 SITRANS TS500, type GP, general purpose, no well
Ød
95 (3.74)
N
E
Welded
Spring
Loaded
E
E
U
U
Ød
Ød
95 (3.74)
95 (3.74)
N
N
U
X
X
X


① SITRANS TS500 type GP (welded)
② SITRANS TS500 type GP (Spring loaded)
③ SITRANS TS500 type GP (Extension)
∅d External diameter of measuring insert
N Nominal length
U Mounting length
X Extension
Figure 12-29 Dimensional drawings SITRANS TS500, type GP, general purpose, no well - dimensions in mm (inch)
