NOTICE
X Extension
Please note for executions without extension but with sealing. To consider the height of the
sealing screw please add this height to your specied insertion length. U = X + U
specied
G50 (M24x1,5): X = 12 mm (½ inch)
G51 (½" NPT): X = 34 mm (1 1/3 inch)
Dimension drawings
12.5 SITRANS TS500
SITRANS TS100/TS200/TS300/TS500/TSinsert/TSthermowell
186 Operating Instructions, 08/2020, A5E47810090-AA
