12.5.11 SITRANS TS500, type SR, threaded reduced well (7MC55..)
Ø6.5
6.5
B=N+H
1
X
1
X
N
L
U
50
U
1
Ø12.7
ØD
H
1
Head bottom thickness:
Type Axx = 41 (1.61)
Type Bxx = 26 (1.02)
B Length of measuring insert
∅D External diameter of process connection N Nominal length
X Extension U Insertion length
U
1
Unsupported length
X
1
Lag length L Length of thermowell
Figure 12-15 Dimensional drawings SITRANS TS500, type SR, threaded reduced well (7MC55…)
Dimension drawings
12.5 SITRANS TS500
SITRANS TS100/TS200/TS300/TS500/TSinsert/TSthermowell
Operating Instructions, 08/2020, A5E47810090-AA 171
