11.1.2.3 SITRANS TS500
Gas Dust
SITRANS TS500 in "intrinsic safety Ex i"
- or -
in "Non-sparking nA/ec"
in "󹪞ameproof enclosure (Ex d)" is part of "intrinsic safety Ex i"
- or -
in "non-intrinsically safe cir‐
cuits (Ex tb)"
Without electronics
(only enclosure
without terminal
socket)
See header TS500 and
relevant temperature class in
Table 11-3 Gas Ex i/nA/ec
(Page 133),
Table 11-4 Gas Ex i/nA/ec
(Page 134),
Table 11-5 Type 2N (Page 134)
and
Table 11-6 Type 2N (Page 135).
See header TS500
without electronics in
Table 11-7 Gas Ex d (Page 135)
and
Table 11-8 Type 2N (Page 136).
See header TS500
without electronics in
Table 11-9 Dust Ex i/tb (Page 137)
and
Table 11-10 Type 2N (Page 138).
With temperature
transmitters
SITRANS TH or
transmitters from
third parties
T
a_max
= (T
1
- ∆T2G) ≤ T
2
T
1
= see relevant certi󹪝cate of the
temperature transmitters.
∆T2G and T
2
= see
Table 11-3 Gas Ex i/nA/ec
(Page 133),
Table 11-4 Gas Ex i/nA/ec
(Page 134),
Table 11-5 Type 2N (Page 134)
and
Table 11-6 Type 2N (Page 135).
See header TS500 with electron‐
ics in
Table 11-7 Gas Ex d (Page 135)
and
Table 11-8 Type 2N (Page 136).
When installing transmitters
from third parties, observe the
maximum permissible power
consumption of 3 W.
See header TS500 with electron‐
ics in
Table 11-9 Dust Ex i/tb (Page 137)
and
Table 11-10 Type 2N (Page 138).
When installing transmitters
from third parties, observe the
maximum permissible power
consumption of 1 W. The maxi‐
mum surface temperature of the
TS500 enclosure is assumed to be
85 °C.
Notice!
If the maximum permissible am‐
bient temperature of the trans‐
mitters from third parties is less
than 85 °C, run the following cal‐
culation:
T
a_max
= T
1
- ∆T1D - ∆T2D
T
1
= see relevant certi󹪝cate of the
temperature transmitters.
∆T1D = 22K (max. permissible
power consumption of 1 W)
∆T2D = See Table 11-9 Dust Ex i/tb
(Page 137) and
Table 11-10 Type 2N (Page 138).
