Parameter assignment
8
8.1 Overview of parameters and functions
Introduction
You can operate the device via local operation or remote operation (e.g. SIMATIC PDM).
• The parameters that you can reach over the device with a display are marked by the
parameter ID. Hereinafter, the parameter ID is always written inside parentheses after the
parameter name. Example: Parameter "Damping value" [04].
• You can access the complete number of parameters via remote operation.
The device-speci󹪝c parameters are available in each tool for con󹪝guration.
The instructions or online help for these tools will provide you with information on how to
use the di󹪜erent tools for parameter assignment.
8.1.1 Parameters and functions
List of parameters and functions
The following parameters are available via the local operation and via remote operation (e.g.
SIMATIC PDM).
The parameters are grouped according to their function in the following overview:
Quick start SIMATIC PDM Device with display
(local operation)
"Quick Start" wizard Menu command "Device > Wizard >
Wizard - Quick start..."
-
Current output SIMATIC PDM Device with display
(local operation)
Set input type "Settings >
Sensor settings" parameter group
Input type 1 [01] (Page 74) /
Input type 2 [04] (Page 78)
Set wiring con󹪝guration "Settings >
Sensor settings" parameter group
Connection type for input 1 [02]
(Page 78) / Connection type for input 2
[05] (Page 81)
Set lower range value
Set upper range value
"Settings >
Current output" parameter group
Lower range value [09]/Upper range val‐
ue [10] (Page 84)
Lower range current
Upper range current
"Settings >
Current output" parameter group
-
Set damping value "Settings >
Sensor settings" parameter group
Damping value [11] (Page 85)
