Current output SIMATIC PDM Device with display
(local operation)
Set current output "Settings >
Current output" parameter group
-
Set saturation limits "Settings >
Current output" parameter group
-
Loop test Menu command "Device >
Loop test"
Loop test [13] (Page 86)
Application SIMATIC PDM Device with display
(local operation)
Select unit "Settings >
Sensor settings" parameter group
Unit [08] (Page 83)
Set the linearization table (60 break‐
points)
"Settings >
Sensor settings" parameter group
-
Set the spline curve (40 breakpoints) "Settings >
Sensor settings" parameter group
-
Change Callendar-Van Dusen coe󹪟‐
cients
"Settings >
Sensor settings" parameter group
-
Calibration SIMATIC PDM Device with display
(local operation)
One-point calibration Menu command "Maintenance > Calibra‐
tion"
One-point calibration input 1 [14]
(Page 88) /
One-point calibration input 2 [15]
(Page 88)
Two-point calibration Menu command "Maintenance > Calibra‐
tion"
-
Identi󹪝cation SIMATIC PDM Device with display
(local operation)
Read and con󹪝gure identi󹪝cation data of
your device
"Identi󹪝cation" parameter group -
Maintenance and diagnostics SIMATIC PDM Device with display
(local operation)
Set fault current for input and output "Maintenance and diagnostics > Measur‐
ing range check mode" parameter group
-
Set fault current for sensor error detec‐
tion
"Maintenance and diagnostics > Error
detection" parameter group
-
Set fault current for drift detection "Maintenance and diagnostics > Drift de‐
tection" parameter group
-
Display of the diagnostics Menu command "Diagnostics > Diagnos‐
tics"
-
Limit monitoring and event counter Menu command "Diagnostics > Device
status"
-
Parameter assignment
8.1 Overview of parameters and functions
SITRANS TS100/TS200/TS300/TS500/TSinsert/TSthermowell
70 Operating Instructions, 08/2020, A5E47810090-AA
