12.5.15 SITRANS TS500, type FS, 󹪞anged straight well (7MC55..)
∅D External diameter of measuring insert N Nominal length
X Extension U Mounting length
X
1
Lag length B Lenght of measuring insert
H
1
Head bottom thickness
Figure 12-19 Dimensional drawings SITRANS TS500, type FS, 󹪞anged straight well (7MC55…)
