1 x RTD TF/3 mm/6 mm
2 x RTD TF/3 mm/6 mm
1 x RTD WW/3 mm/6 mm
2 x RTD WW/3 mm/6 mm
Max. permissible sample temperature (°C)
Certi󹪝ed transmitter in Zone 0 with type of
protection "Intrinsically safe"
Certi󹪝ed transmitter in Zone 1, 2 with
type
of protection "Intrinsically safe"
P0: 0 … ≤37 mW
1)
P0: ≥37 … ≤100 mW P0: 0 … ≤37 mW
1)
P0: ≥37 … ≤100
mW
T4 = 135 °C - 5K 100 92 126 118
T6 = 85 °C - 5K 60 52 76 68
1)
For example SITRANS TH
Thermocouples
Table 11-12 Thermocouple temperature sensor (R
th
max=15 K/W)
1 x TC type J, K, N /3 mm
2 x TC type J, K, N /3 mm
1 x TC type J, K, N /6 mm
2 x TC type J, K, N /6 mm
Max. permissible sample temperature (°C)
Certi󹪝ed transmitter in Zone 0 with type of
protection "Intrinsically safe"
Certi󹪝ed transmitter in Zone 1, 2 with type
of protection "Intrinsically safe"
P0: 0 … 100 mW
T1 = 450 °C -10K 351 439
T2 = 300 °C -10K 231 289
T3 = 200 °C -5K 155 194
T4 = 135 °C -5K 103 129
T6 = 85 °C -5K 63 79
11.1.4 Measuring range
The measuring range refers to the temperature limits in which the thermometer can be used
practically for measuring purposes. Depending on the loads at the place of use and the required
accuracies, the actual measuring range may decrease.
Note
Measuring ranges
The application or possible operating temperatures depend on the con󹪝guration of the
temperature sensor.
Technical data
11.1 Rated conditions
SITRANS TS100/TS200/TS300/TS500/TSinsert/TSthermowell
Operating Instructions, 08/2020, A5E47810090-AA 139
