11.1.2 Maximum permissible ambient temperatures in the connection area of the
sensor
11.1.2.1 General limitations for compression 󹪝ttings
Due to the PTFE sealing, standard compression 󹪝ttings are limited to a maximum temperature
of 200 °C.
11.1.2.2 SITRANS TS100
Note
Application SITRANS TS100
SITRANS TS100 temperature sensors are only approved for the temperature classes T4 and T6.
Pay attention to the temperature resistance of the connection cables. See Ambient temperature
too high (Page 38).
Technical data
11.1 Rated conditions
SITRANS TS100/TS200/TS300/TS500/TSinsert/TSthermowell
128 Operating Instructions, 08/2020, A5E47810090-AA

Siemens SITRANS TSinsert Specifications

General

Communication Protocol	HART
Type	Temperature Transmitter
Output Signal	4 to 20 mA, HART
Sensor	RTD, Thermocouple
Inputs	RTD, Thermocouple
Operating Temperature	-40 to 85 °C (-40 to 185 °F)
Protection Class	IP67
Display	Optional LCD display
