12.5 SITRANS TS500
12.5.1 SITRANS TS500, types 2 and 2N
HN
02U
(0.79)
15
(0.59)
G 1/2"
9 (0.35)
B = N + H
1
1

/(
G
'
+1
% 1+

'
3
/(
① Type 2, pipe version without process connection
② Type 2N, pipe version with screw-in nipple
B Length of measuring insert H
1
Type Axx: 41 (1.61)
Type Bxx: 26 (1.02)
∅d External diameter of measuring insert K Penetration depth
∅D To ①: External diameter of 󹪝xing point (6 (0.24)) LE Cable inlet
∅D To ②: External diameter of process connection N Nominal length
∅D3 Internal diameter of protective tube P Space for process connection
E Thread dimension of process connection U Mounting length
H Height of head X Extension
Dimension drawings
12.5 SITRANS TS500
SITRANS TS100/TS200/TS300/TS500/TSinsert/TSthermowell
Operating Instructions, 08/2020, A5E47810090-AA 159
