8.3.2 Connection type for input 1 [02]
Selects the connection type for input 1 depending on the selected sensor.
Indication on the dis‐
play
WIRING 1
Setting range: 2, 3, 4-wire
Factory setting: 3-wire
8.3.3 Wire resistance for connecting cable at Input 1 [03]
Requirement: Connection type 2-wire
Selects the wire resistance for Input 1.
Indication on the dis‐
play
WIRE RES 1
Setting range: 0 to 100 Ω
Factory setting: 0 Ω
8.3.4 Input type 2 [04]
Selects the input type 2.
Setting range: Display Meaning
NONE No input type selected
P100I Pt100 IEC751
P500I Pt500 IEC751
P1k I Pt1000 IEC751
TC B
1)
Thermocouple Type B IEC 584
TC E
1)
Thermocouple Type E IEC 584
TC J
1)
Thermocouple Type J IEC 584
TC K
1)
Thermocouple Type K IEC 584
TC N
1)
Thermocouple Type N IEC 584
TC R
1)
Thermocouple Type R IEC 584
TC S
1)
Thermocouple Type S IEC 584
TC T
1)
Thermocouple Type T IEC 584
TC L
1)
Thermocouple Type L IEC 584
Factory setting: NONE No input type selected
1)
Can only be selected when the input type TC was also selected for input 1.
Parameter assignment
8.3 Parameter assignment over device with display
SITRANS TS100/TS200/TS300/TS500/TSinsert/TSthermowell
78 Operating Instructions, 08/2020, A5E47810090-AA
