Remote operation Indication on the display Meaning
RTD Nix – GOST 6651-2009
(α = 0.00617)
NIX G RTD Nix
1)
– GOST 6651-2009 (α = 0.00617)
RTD Ni50 – GOST 6651-2009
(α = 0.00617)
N50 G RTD Ni50 – GOST 6651-2009 (α = 0.00617)
RTD Ni100 – GOST 6651-2009
(α = 0.00617)
N100G RTD Ni100 – GOST 6651-2009 (α = 0.00617)
RTD Cux – GOST 6651-2009
(α = 0.00428)
CUX G RTD Cux
1)
– GOST 6651-2009 (α = 0.00428)
RTD Ptx – GOST 6691-2009
(α = 0.00391)
PTX G RTD Ptx
1)
– GOST 6691-2009 (α = 0.00391)
Micro-Volts unipolar
(CUSTOM SPECIFIC)
µV Micro-Volts unipolar (CUSTOM SPECIFIC)
Milli-Volts unipolar
(CUSTOM SPECIFIC)
mV Milli-Volts unipolar (CUSTOM SPECIFIC)
Volts unipolar
(CUSTOM SPECIFIC)
V Volts unipolar (CUSTOM SPECIFIC)
µV bipolar µV± Micro-Volts bipolar
µV unipolar µV± Micro-Volts unipolar
mV bipolar mV± Milli-Volts bipolar
mV unipolar mV± Milli-Volts unipolar
V bipolar V± Volts bipolar
V unipolar V± Volts unipolar
TC Type B - IEC 584 TC B Thermocouple Type B - IEC 584
TC Type E - IEC 584 TC E Thermocouple Type E - IEC 584
TC Type J - IEC 584 TC J Thermocouple Type J - IEC 584
TC Type K - IEC 584 TC K Thermocouple Type K - IEC 584
TC Type L - DIN 43710 TC L Thermocouple Type L - DIN 43710
TC Type Lr - GOST 3044-84 TC LR Thermocouple Type Lr - GOST 3044-84
TC Type N - IEC 584 TC N Thermocouple Type N - IEC 584
TC Type R - IEC 584 TC R Thermocouple Type R - IEC 584
TC Type S - IEC 584 TC S Thermocouple Type S - IEC 584
TC Type T - IEC 584 TC T Thermocouple Type T - IEC 584
TC Type U - DIN 43710 TC U Thermocouple Type U - DIN 43710
TC Type W3 - ASTM E 988 TC W3 Thermocouple Type W3 - ASTM E 988
TC Type W5 - ASTM E 988 TC W5 Thermocouple Type W5 - ASTM E 988
Custom type CUSTM Custom type
Factory set‐
ting:
RTD Pt100 - IEC 751 P100I Pt100 - IEC 751
1)
Value x matches customer RTD value
Parameter assignment
8.3 Parameter assignment over device with display
SITRANS TS100/TS200/TS300/TS500/TSinsert/TSthermowell
Operating Instructions, 08/2020, A5E47810090-AA 77
